PTFE Convoluted Tube Flexible Chemical Resistance | BESTEFLON

Short Description:

Convoluted PTFE tube is available in standard sizes, from 5mm to 50mm ID, with standard wall grades, and excellent chemical, electrical, mechanical and thermal or anti-static properties. Corrugated tubing can be supplied cut to specific lengths, together with either straightened, cuffed or flanged ends for easy connection.

PTFE Convoluted Tubes are made of 100% pure PTFE resin without any pigments or additives. It is suitable for the fields of aviation, chemical industry, food processing, water treatment, and air transportation.

Price: $2.40 - $12.00 / Meter | 100 Meter/Meters (Min. Order)

Lead Time: Quantity(Meters):1 - 2000;Est. Time(days):10

Customization: Customized packaging (Min. Order: 500 Meters)

Payments: T/T

Send email to us Download as PDF

Product Detail

Packaging

Product Tags

Features & Benefits of PTFE Convoluted Tubing:

High flexibility and elasticity.
Temperature range: -65℃ to +260℃
Stable chemical properties, strong corrosion resistance. As a connecting part of a corrosion-resistant pipe has
The advantages of strong rigidity
Greatest resistance to fatigue FDA approved
Flame resistant
Anti-stick properties
Low co-efficient of friction
UV-resistant
Not hygroscopic (water absorption < 0,01%)
Very good dielectric dielectric insulation properties

Convoluted PTFE Tubing Applications:

Electrical cables in the aerospace industry

Light duty chemical transfer hoses

Military vehicles

Food processing industry

Electronics industry

Product Details

Brand Name:	BESTEFLON
Color:	milky white/translucent/black/blue
Specification:	1/4’’-2’’
Material:	100% virgin PTFE
Working Temperature Range:	-65℃-+260℃
Application:	Chemical/Machinery equipment//Compressed gas/Fuel and lubricant handling/Steam transfer/Hydraulic systems
Business Type:	Manufacturer/Factory
Standard:	ISO9001

Convoluted Tube Range

No.	Specification	Outer diameter		Inner diameter		Working pressure		Burst pressure		Minimum bending radius
No.	Specification	(inch)	(mm±0.2)	(inch)	(mm±0.1)	(psi)	(bar)	(psi)	(bar)	(inch)	(mm)
1	1/4"	0.415	10.6	0.256	6.5	60	4	210	14.0	0.787	20
2	5/16"	0.484	12.3	0.315	8.0	60	4	210	14.0	0.866	22
3	3/8"	0.589	15.0	0.394	10.0	60	4	210	14.0	1.024	26
4	1/2"	0.705	17.9	0.512	13.0	60	4	210	14.0	1.024	26
5	5/8"	0.860	21.9	0.630	16.0	45	3	180	12.0	1.260	32
6	3/4"	1.039	26.4	0.748	19.0	45	3	180	12.0	2.165	55
7	1	1.378	35.0	0.984	25.0	45	3	150	10.0	3.150	80
8	1-1/2"	1.772	45.0	1.496	38.0	38	3	135	9.0	3.937	100
9	2"	2.343	59.5	1.969	50.0	30	2	120	8.0	4.921	125
